2023 NEW Released －Ecofriendly, circular-economical, and Luminaire Reusable Conversion Kits LED driver

2023 NEW Released Conversion Kits LED driver－Ecofriendly, circular-economical, and Luminaire Reusable the isolated LED driver | Linear constant current LED driver – non-dimmable

The Conversion Kit LED range is designed for converting Fluorescent Central Battery Emergency lighting into LED Central Battery Emergency luminaire in conjunction with LED T5 tubes and the isolated LED drivers (converters or control gears).

The Conversion Kit range is compatible with the majority of all Central Battery Emergency lighting with T5 fluorescent tubes from 136mm (4W), 212mm (6W), and 288mm (8W). The LED driver is designed in a very small L122xW21xH15mm housing, making it ideal for use in fluorescent exit signs or downlights applications where the space is at a premium.

This range is certified to conform with IEC61347-2-7 standard which makes the converted luminaries easily achieve compliance to IED60598-2-22 standard.

The isolated LED driver features

• Universal AC input / Full range
• For LED loads operating in the Voltage range of 20V - 48 Volts.
• High efficiency up to 90%
• Protections: Short circuit / Over current / Over voltage / Over temperature
• Available with output current range: up to 150mA
• Conform with IEC 60598-2-22 standard and RoHS regulation
• Isolated drivers
• 5 year warranty

Product family benefits

• Conversion kits LED for central Battery Emergency lighting or downlight applications
• Lifetime: up to 100,000h (temperature at T c = 75 °C, max. 10 % failure rate)
• Wide operating temperature range: -40…+65 °C
• Available working with existing ECGsmart LED Light source T5 136mm LED, T5 212mm LED, T5 288mm LED, G24q 5W LED, G24q 6W LED
• Very high efficiency

Applications

• Downlight luminaire
• Emergency lights
• Suitable for Luminaires in limited space

Datasheet download

Benson Energy Saving Technology Co., Ltd (BEST) specialized in the field of manufacturing LED light source and LED driver with more than 10 years. BEST owns exclusive ELECTRONIC BALLAST COMPATIBILITY patents for LED retrofit lights, and We already developed a complete retrofit LED lights based on the Eco-friendly concept. We export retrofit LED lights to Europe, Japan, USA and other countries around the world, and our customers are satisfied with our high-quality products and service.

In order to implement Environment friendly concept, we integrate and design the conversion kit for LED which is a complete set to convert not only the light source but also the external driver (ECG). It can not only to be better extend the entire luminaire lifetime with our LED tubes and external driver and lowest the maintenance cost. Our mission is to implement circular economy in our retrofits lighting products and “USE & REUSE” the luminaire.

We are going to release more and more Conversion kits LED ranges in Dimmable or Non-dimmable, self-contained emergency lighting or non-maintained emergency lighting, commercial LED lighting conversion kits and Smart lighting system. It is time to convert old luminaire to new LED lighting as a new page of lighting generations, and we have all solutions for now and future lighting products, such as providing high quality commercial lighting, and integrating lighting and smart control system. It is our responsibility to implement circular economy and ESG (Environment, Social, Government) spirit in our business and develop a new lighting generation in a sustainable environmental lighting design.

Welcomes all OEM or ODM projects!! We have years experiences, capability, and R&D resources to make any OEM/OEM integration a glowing success! Different conversion kits LED ranges in different fixtures can be well designed according to your design or demand.
