Constant current Linear | Isolated LED driver – non-dimmable
Constant Current Linear | Isolated LED Driver, Non Dimmable LED Driver
Constant current Linear | Isolated LED driver – non-dimmable
Produkt-Bezeichnung: BSP-40WND-200V180FC
No fixture rewiring. Available working with existing BEST ECGsmart LED Light source T5 HE Series.
Add Inquiry
Produktvorteile
No fixture rewiring. Available working with existing BEST ECGsmart LED Light source T5 HE Series.
Features
Universal AC input / Full range
Output Voltage(DC) range of 100V - 200 Volts
with Hotplug features
Protections: Short circuit / Over current / Over voltage / Over temperature
a built-in GaN system based technology
Conform with IEC 60598-2-22 standard and RoHS regulation
Isolated drivers
5 year warranty
Isolated drivers
A built-in GaN system based technology.
Elektrische Daten
| Descriptions | Parameter |
| Nominal input voltage | 100-260V AC |
| Mains frequency | 50/60 Hz |
| Input current | 40-150mA |
| Total harmonic distortion | <10 % |
| Power factor | >0.9 |
| Nominal output voltage | 100V-200V DC |
| Nominal output current | 170mA |
| Output PSTLM | ≤1 |
| Output SVM | ≤0.4 |
| Nominal output power | 40w |
| Galvanic isolation | Isolated |
| Power loss in stand-by mode | <0.25W |
| Product weight | 150g |
| Length | 273mm |
| Width | 29mm |
| Height | 28mm |
| Mounting hole space, length | 264mm |
